GP150 Optic Cable Identifier

A tester integrated OCID and OTDR for cable detection and fault location

Highlights

Allowing testing to be performed simply by connecting the fiber optic cable to the test port without any end-processing or loopback
With up to 100 km test distance, it can meet the long-distance needs of intercity trunk lines and other long-distance lines
Avoid crosstalk between adjacent optical cables when distinguishing multiple closely laid optical cables, ensuring the result accuracy
Work regardless of whether the cable is terminated with a PC or APC connector, or even a non-reflective end face. No need to demage optic fibers.
Real-time audio prompts are combined with waveform display. When the target optical fiber cable is knocked or disturbed, the device will sound an alarm and display the unique waveform characteristics on the screen.

Optical cable identification and location
OTDR optic fiber test
Lossless test

Specifications

Model / Items	GP150
Measure Mode	Singal Fiber Test (No loopback)
Wavelength	1550 nm ±20 nm
Test Distance	40 km / 100 km
Undirectional Cable Loss	14 dB/24 dB
Real-time Waveform Display	Yes
Real-time Audio Prompt	Yes
Initial Blind Area	No
Signal-to-noise Ratio	> 10 dB
LCD Touch Screen	5.6 inch
Optical Fiber Type	SMF
Optical Connectors	FC/APC
Battery Life	Over ten hours

Use Cases

Communication operator equipment room construction and line upgrading

Optical cable cutover and resource survey

Optical cable maintenance and fault repair

Cable location in complex environments such as pipelines, tunnels, and manholes

TFN GP150 is specifically designed for telecom engineers and fiber optic cable maintenance personnel, enabling fiber optic cable identification and fault location in diverse complex environments such as manholes, tunnels, conduits, and utility poles. Utilizing non-destructive detection technology, this device offers simple operation and precise identification, making it an ideal tool for fiber optic cable maintenance and resource management.

Product Demo

FAQs

What’s the test distance?

GP150 supports 40km test.

What’s the lead time?

For our standard products, if there are in stock and ready for shipment, the lead time is about 7-10 days. For our optional products, the lead time is about 25-30 days.

Do you support online training?

Yes. We understand the importance of proper operation of professional instruments.

Basic Training: We provide a detailed English operating manual.

Online Remote Training: We can provide real-time online operation training and Q&A for you and your team via video conferencing software (such as Zoom and Teams).

On-site Training: Based on project requirements, we can arrange for our engineers to conduct in-depth on-site training (travel expenses are subject to negotiation).

Training content can be customized to your specific application scenario.
