TM9265 Directional Antenna kit

A handheld ultra-wideband directional antenna set is for radio monitoring and signal location

Característica

One set of equipment covers five key frequency bands (9KHz-30MHz, 20MHz-200MHz, 200MHz-500MHz, 500MHz-8GHz, 6GHz-26.5GHz), enabling full monitoring from longwave to millimeter wave
Combining a cardioid linear pattern (front-to-back ratio >10dB) with a 3D electronic compass, it accurately indicates the direction of incoming signals in real time
The single antenna module weighs only 1kg, and most weigh less than 0.55kg. It is designed for long-term handheld operation and rapid mobile deployment
The universal intelligent handle integrates a “start measurement” button, supports USB or aviation plug power supply and data output, and is easy to operate and ready to use.
Users can quickly replace antenna modules of different frequency bands according to mission requirements, flexibly responding to various complex electromagnetic environments.

Solicitar cotización

parámetros de configuración

Antenna Model	Frequency range	Standing Wave Ratio	Front-to-back ratio	Gain	Dimensions	Peso
TN315A	9KHz ~ 30MHz	< 2.5	> 10dB	-170dBi ~ -25dBi	530mm * 300mm * 40mm	0.5 kg
TN315B	20MHz ~ 200MHz	< 2.5	> 10dB	-28dBi ~ +7dBi	530mm * 300mm * 90mm	0.45 kg
TN315C	200MHz ~ 500MHz	< 2.5	> 10dB	-5dBi ~ +7dBi	380mm * 260mm * 40mm	0.25 kg
TN315D	500MHz ~ 8GHz	< 2.5	> 10dB	-5dBi ~ +18dBi	540mm * 260mm * 40mm	0.55 kg
TN315E	6GHz ~ 26.5GHz	< 2.5	> 10dB	+10dBi ~ +20dBi		1.0 kg

Universal smart handle–TN315F
Start measurement button	one-click triggering of data acquisition
Data interface :	USB2.0 / 9-pin aviation plug
RF output interface :	SMA (male)
Power supply	USB (5V) / 9-pin aviation plug (5V)
Built-in sensors	high-precision GPS, three-dimensional electronic compass

Application Scenarios

Radio Management and Spectrum Monitoring
Signal source positioning and tracking (such as drone interference sources, illegal radio stations)
Educational Experiments and Scientific Research Measurement
Emergency communications and security inspections
EMC pre-compliance testing
